Apache 160





ENGINE & TRANSMISSION
Type4 Stroke, 159.7 cc, Single
Max. Power11.19 Kw (15.2 Bhp) @ 8500 rpm
Max. Torque13.1 Nm @ 6000 rpm
Bore & Stroke62mm X 52.9 mm
Compression Ratio9.5:1
CarburettorMikuni BS-26
Valve Train2 Valves, Single Cam
Valves Per Cylinder2 Valves
Power to weight ratio111.76 Bhp / Ton
StartingElectric & Kick Start
IgnitionIDI-Dual mode digital ignition
TRANSMISSION
ClutchWet, Multi-Plate
Gear5 Speed
CHASSIS
TypeDouble Cradle
SUSPENSION
FrontTelescopic Forks, 105mm Stroke
RearMonotube Inverted Gas filled shox (MIG) With Spring Aid
BRAKES
Front270 mm Petal Disc
Rear130 mm Drum
WHEELS AND TYRES
Rim size (Front)1.85 x 17"
Rim size (Rear)2.15 x 18"
Tyre size (Front)90/90 x 17"
Tyre size (Rear)100/80 x 18"
ELECTRICAL
Head lamp35/35W Halogen HS1, Clear lens with MFR
Tail lamp5 W
Stop lamp21 W
Turn signal lamp10 W
DIMENSIONS & CAPACITY
Length2020 mm
Width730 mm
Height1050 mm
Wheelbase1300 mm
Saddle Height790 mm
Ground Clearance180 mm
Fuel tank capacity16.0 lit
Reserve capacity2.5 lit
Useable Reserve1.7 lit
Fuel Economy
Fuel Economy (IDC)45 Kmpl*
