ENGINE | |
Type | 4 Stroke, Single cylinder, Air Cooled, OHC |
Displacement | 109.7 cc |
Maximum Power | 5.88 KW @ 7500 rpm |
Maximum Torque | 8Nm @ 5500 rpm |
Starting | Electric & Kick Start |
Transmission | Primary CVT & Secondary Gear Box |
Ignition | Digital IDI with Ignition Map Technology |
Electricals | |
Battery | 12V, 5 Ah Flooded |
Head Lamp | 12V, 35/35W Halogen (Multi-reflector Type) |
Brake Lamp / Tail Lamp | 12V, 2W/1.5W LED |
Turn Signal Lamp | 12V - 10W(Amber Bulb) x 4 Nos. (Multi-reflector Clear Lens |
CHASSIS | |
Frame | High Rigidity Underbone Type |
Dimensions (l x b x h) | 1834 x 650 x 1115 mm |
Wheelbase | 1275 mm |
Saddle Height | 765 mm |
Ground Clearance | 150 mm |
SUSPENSION | |
Front | Advance Telescopic Suspension |
Rear | Hydraulic & Gas Filled Suspension |
BRAKES | |
Front | 130 mm Drum Brake |
Rear | 130 mm Drum Brake |
TYRE SIZE | |
Front | 90/90-12, Tubeless |
Rear | 90/90-12, Tubeless |
AIR FILTER | |
Air filter | Viscous Paper Filter |
FUEL TANK CAPACITY | |
Fuel Tank Capacity | 5.0 Litres |
Fuel Economy | |
Fuel Economy (IDC) | 62 Kmpl* |
